LITZ MV-1000 CNC VERTICAL MILLING

TECHNICAL FEATURES:

TRAVEL

X Travel 1000 mm (39.37 inch)
Y Travel 500 mm (19.7 inch)
Z Travel 540 mm (21.3 inch)

Spindle nose to table

100- 640 mm (3.94-25.2 inch)

SpindleSpeed -8000 rpm

FOCASEIKI PM-860 CNC VERTICAL MILLING

TECHNICAL FEATURES:

TRAVEL

X Travel 800 mm (31.5 inch)
Y Travel 600 mm (23.62 inch)
Z Travel 600 mm (23.62 inch)

Automatic tool changer

SpindleSpeed -8000 rpm

LITZ LV-660 CNC VERTICAL MILLING

TECHNICAL FEATURES:

TRAVEL

X Travel 660mm)
Y Travel 40mm
Z Travel 540 mm

Spindle nose

BT 40

SpindleSpeed -10000 rpm

FOCASEIKI -TP 750 CNC VERTICAL MILLING

TECHNICAL FEATURES:

Table Size - 700x400 mm
M/C Weight - 4200 kgs
Travel xyz - 700x500x500 mm
Spindle Nose - BT40
Spindle Max Speed - 12,000 rpm
Spindle Motor - 15 hp
ATC- 24 tool
Cycle - 50HZ

CNC VERTICAL MILLING

TECHNICAL FEATURES:

X Axis Travel - 7.9"
Y Axis Travel - 17.3"
Z Axis Travel - 12.0"
A Axis (deg.) - 120 - -30
C Axis (deg.) - 360
Spindle RPM -10,000/16,000
Tapping RPM -6,000
Rapid Traverse - 1,969 IPM

ROBO DRILL MACHINE

TECHNICAL FEATURES: Axis X - 500 mm
Axis Y - 380 mm
Axis Z - 300 mm
Table length - 650 mm
Table width- 400 mm
Max. part weight - 200 kg
Number of tool pockets - 3
Spindle taper - MAS BT 30
Max. spindle speed - 8000 rpm

SENYANG HORISONTAL LATHE MACHINE-CW6280

TECHNICAL FEATURES:
Max swing diameter over bed: 800 mm
Max swing diameter over carriage 480 mm
Max. workpiece length 3000 mm

GOODWAY GCL-2L CNC LATHE

TECHNICAL FEATURES:
MMax. swing diameter - 400mm
Swing over saddle - 280mm
Max.turning diameter - 250mm
Std.turning diameter - 220mm

HASEGAWA CHAMP - 21 MACHINE (JAPAN)

TECHNICAL FEATURES:
Turning dia.length mm: Dia 250X200 mm
Max.turning diameter mm: Dia 200mm
chuck: 6”
Rapid traverse rate m/min:25 m/min

VERTICAL MACHINING CENTER CV–800

TECHNICAL FEATURES:

TRAVEL

X Travel 800 mm
Y Travel 450 mm
Z Travel 540 mm

Spindle nose to table

80-620 mm

SpindleSpeed -10000 rpm

DMG CTX 310 ECOLINE

TECHNICAL FEATURES:

Max Swing Diameter - 330 mm
Max Turning Diameter - 200 mm
Stroke in Z axis - 455 mm
Max Chuck Diameter - 210 mm
Bar Capacity - 51 mm
Spindle Speed - 4,000 rpm

TOP WELL CONVENTIONAL MILLING

TECHNICAL FEATURES

Capability

Max Machine capability: (600*380)mm
Tolerance control: +/- 0.02mm

CPL 30 CAMPRO CNC LATHE

TECHNICAL FEATURES:
Chuck Size - 249.43 mm
Power - 19.4 kW
Max RPM - 3,000 RPM
Turning Dia - 297.18 mm
Swing - 497.84 mm
Machining Length - 596.9 mm
Tailstock - Yes
Control - CNC

CPV-1100

TECHNICAL FEATURES:

TRAVEL

X Travel 43.3"
Y Travel 24.4"
Z Travel 23.6"

Automatic tool changer

SpindleSpeed -12000 rpm

TAIWAN TAKIWASA CNC LATHE EX-106

TECHNICAL FEATURES: wing over bed - 360 mm (14.12”)
Maximum Turning length -325 mm (12.75”)
Bar Work Capacity - 43 mm (1.69”)
Spindle Speed - 60-6000 rpm
Spindle Nose - FLAT 140 mm (5.51”)
Through Hole Ø - 56 mm (2.2”)
Stroke of X axis - 280mm (11”)
Stroke of Z axis - 325mm (12.75”)

REINSHAW MH20i

TECHNICAL FEATURES: Positional Repeatability - (2σ) 1.5μ m
Maximum extension bar - Em2 module 94.5mm
Sense Direction + ±X ±Y +Z
A axis 0°to 90°in 15°increments
B axis ±180°in 15°increments
Spatial Position: 168

LITZ CV-800 CNC VERTICAL MILLING

TECHNICAL FEATURES:
X Travel 800 mm (31.5 inch)
 Y Travel 500 mm (19.7 inch)
 Z Travel 540 mm (21.3 inch)
Tool number 24
 Max tool diameter 100mm ( 3.9 inch)
 Max tool length 305 mm ( 12.0 inch)
 Max tool weight 7kg ( 15.4 lb)

LAGUN CONVENTIONAL MILLING MACHINE

TECHNICAL FEATURES:
Max Machine capability: (600*380)mm
Tolerance control: +/- 0.02mm
